Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)
Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)
Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)
Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)
Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)
Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)
Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)

Miller Filtair Capture 5 (575V) w/12-Ft Extraction Arm (951595)

Sale price$3,280.00 Regular price$3,788.00
Sold out

Earn
Rewards points when you’re a Rewards member. Sign up or Login here
warning WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov

This product is no longer available. You can find more Miller fume extractors here.

The Capture 5 features completely new and exclusive ZoneFlow™ technology, which creates a much larger capture area than existing source-capture products and minimizes arm interactions. Capture 5 is far more effective than ambient fume extraction systems.

Features
• Extended fume capture up to 5 ft from nozzle
• Larger weld area = less arm interaction
• Best in-class filter
• Automatic filter cleaning extends filter life
• Balanced arm design is easy to move and stays in position
• Pre-assembled arm, featuring convenient 360-degree rotation for unlimited positioning
• Lockable swivel casters

Quick Specs:
• Filter Media 452 ft.2 (42 m2)
• Accu-Rated™Airflow 900 CFM (425 L/sec.)
• Sound Level Approximately 77 dBA at 5 ft. (1.5 m)
• Motor Specifications 3 HP
• Dimensions H: 43 in. (1092 mm) | W: 36 in. (915 mm) | D: 48 in. (1219 mm)
• Extraction Arm 10-in. (254 mm) diameter (10 or 12-ft. lengths available)
• Weight 660 lb. (300 kg) for extractor with 12-ft. arm
Input Power: 575 V, 3-phase, 60 Hz at 3.0 A
