Weldtec 12ft Speedway Deluxe TIG Torch Package (SW-320-12DX)
Weldtec makes some of the most popular TIG torches on the market including the water-cooled Speedway series. The Speedway series torches bring together the best in design, materials, and workmanship to achieve unprecedented performance. As always, Weldtec products are made in the USA.
Speedway Features
• Silver brazed copper construction - increases current capacity and dissipates heat most efficiently
• Resilient silicone rubber insulation - resists "HF" current leakage, chipping, and cracking
• Flexible over braided rubber hoses - more flexible than vinyl
• Speed Nut hose connections - no tools or special hose assemblies required
• Speed Bump - ergonomic handle shape, handle can be rotated 360 degrees for optimum position
Quick Specs:
• Max Amperage: 320 Amps
• Weight (torch body and handle): 3.0 oz
• Tungsten size capacity: .020" - 5/32"
• Max Tungsten length: 7"
• Cooling requirements: 1 quart/min
• Coolant pressure requirements: 50 psi
Deluxe Torch Package Includes:
• Torch body
• Handle
• 12.5ft Over braided rubber hoses and power cable
• Premium leather cable cover
• 3/32" Collet and Collet Body
• #6 Alumina Nozzle
• 3/32" x 7" Tungsten Electrode
• 1 short, 1 medium, and 1 long back cap
Speedway Features
• Silver brazed copper construction - increases current capacity and dissipates heat most efficiently
• Resilient silicone rubber insulation - resists "HF" current leakage, chipping, and cracking
• Flexible over braided rubber hoses - more flexible than vinyl
• Speed Nut hose connections - no tools or special hose assemblies required
• Speed Bump - ergonomic handle shape, handle can be rotated 360 degrees for optimum position
Quick Specs:
• Max Amperage: 320 Amps
• Weight (torch body and handle): 3.0 oz
• Tungsten size capacity: .020" - 5/32"
• Max Tungsten length: 7"
• Cooling requirements: 1 quart/min
• Coolant pressure requirements: 50 psi
Deluxe Torch Package Includes:
• Torch body
• Handle
• 12.5ft Over braided rubber hoses and power cable
• Premium leather cable cover
• 3/32" Collet and Collet Body
• #6 Alumina Nozzle
• 3/32" x 7" Tungsten Electrode
• 1 short, 1 medium, and 1 long back cap
| MPN: | WLTSW-320-12DX |
|---|
MPN: WLTSW-320-12DX
